Epigraphers press damp paper into carved letters to take a squeeze - in Romanian an estampaj or calc: the stone's negative. Turn it on to study every stone in relief.

AVLA I · ANTIQVITAS · c. 150 - c. 350

Two Roman instruments, neither a picture in the modern sense: a table of coordinates and a strip-diagram of roads. Between them they fix Dacia in number and in itinerary - and both will be copied for a thousand years by hands that never saw the place.

I · PTOLEMY · GEOGRAPHIA III.8 · DACIA

Dacia enters geometry: forty-four towns hung on coordinates. Content c. A.D. 150, recovered c. 1295, first printed with maps 1477. Klaudios Ptolemaios, Alexandria: a coordinate catalogue, every drawing of it a later restoration.

Corpussrc-ptolemy-geographia in cnd-0.1 · 4 records, 1 of them a silence · on the Atlas

Book III, chapter 8 of the Geographia fixes Dacia between the Tisia, the Danube and the Hierasus and then lists its contents: some forty-four towns with latitude and longitude, fifteen tribes, and a royal seat - Zarmizegethousa basileion. Many of the names carry the native -dava ending, “settlement,” in Greek dress: Piroboridava, Ziridava, Sucidava. The land has been converted into a coordinate system.

The work survived as text. Recovered for the West around 1295 - Planudes may have re-drawn the maps from the numbers alone - and printed with maps at Bologna in 1477, it handed the Renaissance a Dacia that was pure data, waiting to be plotted. The first stone in the wall is not a picture at all.

Find. Dacia first becomes a set of numbers: every town a latitude, every error a coordinate.

Nota. Ptolemy’s “map” of Dacia is a table. Every drawing of it - Byzantine, Renaissance, modern - is a reconstruction from the numbers, which is why the numbers outlived every sheet.

II · TABVLA PEVTINGERIANA · SEGM. VII–VIII

A province four fingers tall: the roads survive the map. Content c. 4th century, surviving copy c. 1200. Unknown imperial compilers and a medieval copyist; a parchment roll of eleven segments, c. 6.75 m × 34 cm, now ÖNB Vienna, Cod. 324, inscribed in the UNESCO Memory of the World register in 2007.

Corpussrc-tabula-peutingeriana in cnd-0.1 · 4 records · on the Atlas

Nearly seven metres long and only thirty-four centimetres tall, the Peutinger roll squeezes the known world into a ribbon. Geometry is sacrificed wholesale to connection: this is route-bearing space, not a portrait - the world ordered by what the road joins rather than by where things lie. Across segments VII–VIII the Dacian roads climb north of the Danube - Lederata to Tibiscum, on to Sarmategte, Apula, Napoca, Porolisso - each station with its mileage, in the brisk Latin of a road-book.

Aurelian abandoned the province around 271–275; the roll’s 4th-century content keeps the roads anyway, and a scribe around 1200 copied them again, checking distances but never shapes. The archive outlived the territory it described.

Find. The map remembers what the empire forgot: Dacia’s roads outlive Dacia by a century of parchment.

Nota. Pompeii (destroyed A.D. 79) and Constantinople (founded 330) share the same roll

• a palimpsest of centuries that copying flattened into one sheet.

AVLA II · NOMEN ERRANS · THE WANDERING NAME · c. 1300

In which the name leaves the land. Chancery Latin and a Dominican province carry DACIA to Denmark; the Carpathian country, meanwhile, is filed under other people’s ghosts.

III · HEREFORD MAPPA MVNDI · DACIA IN EXILE

The name leaves for Denmark; the land is filed under ghosts. c. 1300, from the circle of Richard of Haldingham. A single calf-skin, c. 1.58 × 1.33 m, east at top, still at Hereford Cathedral - intact, on its original wall more or less ever since.

Corpussrc-hereford-mappa in cnd-0.1 · 4 records, 4 of them silences · on the Atlas

On the great skin at Hereford the label DACIA sits in Scandinavia. This is not a blunder but usage: by the thirteenth century chancery Latin used Dacia for Denmark, and the Dominican province of that name (1228) fixed the habit. The Carpathian–Danubian country, meanwhile, is dressed in inherited ghosts - Moesia, Gothia, Scythia - with crusade-era names crowding in from the documents: Cumania, terra Blacorum.

The map is ordered by theology, east at the top, Jerusalem at the centre. Authority and inherited text supply everything; observation supplies nothing. The people of the land persist in the charters even as the cartographers misplace its name by two thousand kilometres.

Find. The word DACIA migrates to Denmark; the land it named drops out of cartography’s vocabulary.

Nota. The Dominicans’ Provincia Daciae (1228) covered Scandinavia - so in chancery Latin “Dacia” meant Denmark for centuries, while papal files called the real country the Diocese of Cumania (1227/28) and terra Blacorum.

AVLA III · LITORA · THE COASTS · 1311

The sea is surveyed before the land. Genoese and Venetian pilots, working the Black Sea after the Treaty of Nymphaeum (1261), draw the coast to a precision the interior will not see for five centuries.

IV · PIETRO VESCONTE · PORTOLAN OF THE BLACK SEA

A centimetre-true coastline around a perfect void. Signed chart 1311, in a tradition running back to the Carte Pisane, c. 1290. Pietro Vesconte, Genoese, working in Venice: ink on vellum, its rhumb network struck from hidden circles, with no graticule at all.

Corpussrc-vesconte-portolan in cnd-0.1 · 4 records, 4 of them silences · on the Atlas

After the Treaty of Nymphaeum (1261) opened the straits, Genoese and Venetian pilots worked the Black Sea hard - and their charts show it. Vesconte’s coastline runs with startling precision: the Danube’s arms, then the ports written perpendicular to the shore in red and black - Licostomo (Chilia), Moncastro (Cetatea Albă), Vicina somewhere on the lower river, Costanza.

There is no graticule; the web of compass bearings is the geometry. Each crossing corrected the last - iterative proofreading by keel. One league inland, the parchment goes silent: the chart answers only the questions a pilot asks.

Find. The sea taught Europe to measure before the land did.

Nota. Moncastro and Cetatea Albă are one fortress in two ledgers - Genoese and Moldavian names for the same white castle on the Dniester liman. Vicina, richest port of the lower Danube, is still missing: its exact site remains debated.

AVLA IV · RENASCENTIA · RECOVERY BY PRINT · 1532 - 1595

Print arrives. Lazarus’s Tabula Hungariae (1528) shows the region first; Honterus gives Transylvania its own sheet; Ortelius restores a Dacia that no longer exists. Recovery and invention, on the same presses.

V · HONTERVS · CHOROGRAPHIA TRANSYLVANIAE

A native woodcut: the country as a walled garden seen from above. Basel, 1532, reworked into the Rudimenta Cosmographica at Brașov in 1542. Johannes Honterus, Saxon humanist of Kronstadt: a printed woodcut, pictorial chorography, no graticule. A single known print survives, likely in Budapest.

Corpussrc-honterus-chorographia in cnd-0.1 · 4 records, 2 of them silences · on the Atlas

In Basel in 1532 a Saxon humanist of Kronstadt cut his homeland in wood: the first separate printed map of Transylvania, made from inside it. The Carpathians stand as molehill ranges around the rim; within the ring, towers and trees crowd a country he had walked - hundreds of names, German foremost, with Hungarian and Romanian beneath.

This is chorography rather than geodesy - the land as a portrait, dense to the edges, with hardly a blank to decorate. A decade later he folded the matter into his Rudimenta Cosmographica (Brașov, 1542), and the schoolbooks of half of Europe carried his Transylvania for a century.

Find. The first map of Transylvania drawn by someone who had slept in its towns.

Nota. Lazarus’s Tabula Hungariae (1528) showed the region first; Honterus gave Transylvania its own sheet. A single print of 1532 is known to survive - and the claim that he set south at the top is repeated more often than it is proven.

VI · ORTELIVS · DACIARVM MOESIARVMQVE VETVS DESCRIPTIO

A modern graticule lent to a vanished province. Parergon, Antwerp, 1595, first state. Abraham Ortelius’s own compilation: a copper engraving in his atlas of antiquity, with current coastline geometry carrying 2nd-century content.

Corpussrc-ortelius-parergon in cnd-0.1 · 4 records · on the Atlas

For the humanists, Dacia lived more vividly in Tacitus than in the Ottoman-vassal principalities of their own day. In the Parergon - his atlas of antiquity - Ortelius drew it back: Ptolemy’s towns, the legions’ stations, Pons Traiani across the Danube, all laid on a respectably modern coastline and graticule. Every name is a citation; the map carries its own apparatus.

The title declares the method: vetus descriptio, the old description. The sixteenth century - Wallachia, Moldavia, the Porte - is deliberately absent. A province dead for thirteen centuries returns to print before the living country does.

Find. Dacia comes home through philology - by way of Denmark.

Nota. Ortelius died in 1598 with the expanded Peutinger plates literally in press; they appeared that December. The Parergon’s title says it plainly: vetus descriptio - the old description, the present declined.

AVLA V · PRINCIPES · THE PRINCES’ MAPS · 1700 - 1737

Two native cartographies a generation apart - Wallachia engraved in Greek, Moldavia remembered in Latin - each a country drafting its own portrait.

VII · CANTACVZINO · WALLACHIA IN GREEK

A country drafting itself in someone else’s alphabet. Padua, 1700, with a reduced copy in Del Chiaro, 1718. Constantin Cantacuzino, stolnic, printed by Chrysanthos Notaras: a copper engraving on four sheets, in Greek, carrying 500+ toponyms drawn from administration. Nearly lost; a handful of copies survive, one at the BnF.

Corpussrc-cantacuzino-wallachia in cnd-0.1 · 4 records, 3 of them silences · on the Atlas

In 1700 a Padua-trained stolnic had his country engraved - in Greek, on four sheets, at Padua, the first map of Wallachia by a native. Counties, monasteries, salt-works: over five hundred places, written by the administration that knew them, each Romanian name wearing a Greek transliteration like a borrowed coat.

The frame and conventions are Venetian; the knowledge is local. The graticule sits lightly, more proposed than enforced. It survives in a handful of copies and in Del Chiaro’s 1718 reduction - a sovereignty rehearsed on paper a century and a half before it could be declared.

Find. A country drafting itself into existence in someone else’s alphabet.

Nota. Seen through the press by Chrysanthos Notaras - Cantacuzino’s disciple, later Patriarch of Jerusalem - and likely dedicated to Constantin Brâncoveanu. The villages were set down by the men who collected their tithes.

VIII · CANTEMIR · PRINCIPATVS MOLDAVIAE

A prince’s memory of his country, printed in exile. Drawn c. 1716 for the Descriptio Moldaviae, engraved at Amsterdam in 1737. Dimitrie Cantemir, Prince of Moldavia and member of the Berlin Academy: an ordered frame with an interior drawn from memory, some 800 names deep. The manuscript wandered to Russia; the print carried the content.

Corpussrc-cantemir-moldavia in cnd-0.1 · 4 records, 4 of them silences · on the Atlas

Deposed in 1711, Dimitrie Cantemir mapped Moldavia from exile: roughly eight hundred names, the ținuturi drawn out like a ledger, rivers from the Carpathians to the Dniester - the first detailed map of the principality from native knowledge, made to accompany the Descriptio Moldaviae he wrote for the Berlin Academy.

No instrument confirms it; the interior bends to memory, and is denser than anything an instrument had yet produced. He died in 1723. The map appeared at Amsterdam in 1737 - Principatus Moldaviae nova & accurata descriptio - a country remembered more thoroughly than it had ever been measured.

Find. A prince’s memory of his country, printed in exile, fourteen years after his death.

Nota. Drawn c. 1716 to accompany the Descriptio Moldaviae written for the Berlin Academy; engraved at Amsterdam in 1737, his son Antioh - Russia’s ambassador - seeing it through the press.

AVLA VI · IMPERIA · THE EMPIRES MEASVRE · 1769 - 1835

Habsburg plane-tables and Russian triangles produce the most accurate maps the land has known - and lock them away. Accuracy and secrecy, born twins.

IX · IOSEPHINA · FIRST MILITARY SVRVEY OF TRANSYLVANIA

Accuracy and secrecy, born twins. Transylvania 1769–73, Banat 1769–72, Bukovina 1773–75. Habsburg General Staff plane-table parties: hand-coloured manuscript, c. 280 sheets at 1:28,800, held in the Kriegsarchiv, Vienna - classified from birth, and complete because locked away.

Corpussrc-iosephina-survey in cnd-0.1 · 5 records, 1 of them a silence · on the Atlas

After the Seven Years’ War the Habsburg staff resolved to know exactly what they ruled. Transylvania was taken at 1:28,800 in 1769–73, plane-table parties walking every valley: each mill, ford and tavern drawn, each road annotated for the march - which bridges bear cannon, where a column can water.

The sheets were never meant for eyes outside the staff. Hand-coloured, hundreds strong, they went into Vienna and stayed there: the most accurate portrait the land had ever received, and the one it was not allowed to see. From here on, accuracy and secrecy travel together.

Find. Accuracy becomes armament: the sheet records which bridges bear cannon.

Nota. Roughly 280 manuscript sheets for Transylvania alone, with written military commentary on every road and ford. The Second Survey (1806–69) added triangulation - measured everything twice, and classified it both times.

X · RVSSIAN GENERAL STAFF · THE PRINCIPALITIES

Triangulation gives error a number and a sign. Surveyed after 1829, published 1835. The Russian General Staff under Kiselyov’s administration: engraved at 1:420,000, the first triangulation of Wallachia and Moldavia. The triangles outlived the occupation by half a century.

Corpussrc-russian-staff-1835 in cnd-0.1 · 4 records, 3 of them silences · on the Atlas

The Treaty of Adrianople left Russia administering the Principalities, and Kiselyov’s officers did what occupying staffs do: they measured. For the first time Wallachia and Moldavia received a triangulation - a network of computed points against which every later survey could take residuals. Error finally had a number and a sign.

Published in 1835 at 1:420,000, with Romanian names re-spelled in Russian Cyrillic, the map was a general staff’s instrument, shared sparingly. Its triangles, though, proved durable: the Romanian state that emerged a generation later built its own cartography on an occupier’s skeleton.

Find. The new state will inherit its geometry from its occupier.

Nota. After Adrianople (1829), Russian officers under Kiselyov ran the first triangulation of Wallachia and Moldavia; the 1:420,000 sheet of 1835 underlay Romanian mapping for half a century.

AVLA VII · NATIO · THE NATION PRINTS · 1864

A new state prints its name. On the occupiers’ geometry, with a freshly decreed alphabet, ROMÂNIA appears in Latin type across its own territory.

XI · CHARTA ROMÂNIEI MERIDIONALE

The country prints its own name across itself. Printed in Vienna, 1864, under Cuza, commonly attributed to Carol Popp de Szathmári as editor under military oversight: a lithograph of c. 112 sheets at 1:57,600, built on the Austrian survey of the 1850s and field-updated. Plentiful - the first deliberately public state map.

Corpussrc-szathmari-charta in cnd-0.1 · 4 records, 3 of them silences · on the Atlas

Union in 1859; the name România adopted in 1862; the Latin alphabet decreed the same year after decades of drift. Two years later the young state issued its first great map: southern Romania at 1:57,600 across some 112 sheets, printed in Vienna, commonly attributed to Cuza’s court artist Szathmári as editor under military oversight.

The geometry is openly inherited - the Austrian survey of the 1850s beneath, the Russian triangles before that - verified and updated in the field. What is new is the writing: ROMÂNIA in Latin type across its own territory, the alphabet changing hands on the sheet itself.

Find. The country prints its own name across itself: ROMÂNIA, in Latin letters, 1864.

Nota. Szathmári photographed the Danubian front in 1854 - among the first war photographers anywhere - and a decade later lithographed his country. The state was named România in 1862; the Latin alphabet was decreed the same year.

AVLA VIII · SAECVLVM SECRETVM · THE SECRET CENTVRY · 1916 - 1989

Artillery grids, Soviet projections, decreed toponyms, falsified public sheets: the truest maps ever made of this land, and the least seen.

XII · THE SECRET CENTVRY · PLANVRI & STEREO 70

One true map in the safe, one false map at the kiosk. Lambert–Cholesky adopted 1916–17; some 2,118 sheets to the 1950s; Gauss–Krüger after 1951; Stereo 70 decreed 1973. The Army Geographic Service, the French mission under Berthelot, then Soviet standards: printed topographic sheets at 1:20,000, classified. Complete and long unseeable, its public derivatives deliberately false.

Corpussrc-secret-century in cnd-0.1 · 4 records · on the Atlas

War brought the grid. With Berthelot’s French mission came the Lambert–Cholesky projection and the planurile directoare de tragere: 1:20,000 sheets, some 2,118 of them by the 1950s, drawn so that artillery arithmetic would land where it was aimed. After 1951 the Soviet standards took over - Krasovsky ellipsoid, Gauss–Krüger - and the true map went into the safe.

Stereo 70, decreed in 1973, gave Romania its own secant plane near Făgăraș and kept the locks. Public maps were schematic by design; a 1964 decree renamed hundreds of villages at a stroke. The most accurate cartography the land had ever had, and the least seen: two maps of one country, one true and hidden, one false and for sale.

Find. The state keeps the true map in a safe and sells the false one at the kiosk.

Nota. The Lambert–Cholesky grid arrived with Berthelot’s French mission in 1916–17; André-Louis Cholesky, whose decomposition every engineer still uses, computed for it and died on the Western Front in 1918. Stereo 70, decreed 1973, still rides the Krasovsky ellipsoid.

AVLA IX · PRAESENS · THE PRESENT SVRVEY · 2026

One datum for everyone, imagery every few days, edits by the minute - and the thirteenth stone left rough, because the wall is not finished.

XIII · THE PRESENT SVRVEY · WGS84 / SENTINEL / OSM

The thirteenth stone, left rough on purpose. Continuous: re-imaged every few days, edited every minute. States, firms and volunteers, authority dissolved among them: pixels and vectors, a datum in every pocket. WGS84, Sentinel-2 at 10 m, OSM by the minute - everywhere and nowhere, in caches, mirrors and tiles, where revision outruns preservation.

The present layer barely needs carving. One datum - WGS84 - serves everyone; Sentinel-2 re-images the country at ten metres every few days; volunteers revise the map faster than any censor could redact it. The old readings persist in new forms: restitutio is now interpolation and training data, rasura a blurred compound or a proprietary tile, vacat nearly extinct.

So the stone is left rough - a few orbital scratches, a pin, the coordinates of Cluj. Each generation has believed it finally finished the map. The wall knows better, and keeps space.

Find. Everyone now carries a survey the old regime would have killed for.

Nota. The thirteenth stone is left mostly uncarved on purpose: Sentinel-2 re-images the country every few days, OSM edits the land by the minute, and the wall reserves space for whatever instrument comes next.
